Sheet-fed featured C1 model can be used for roll to roll printing too when the printing speed is not required too high. It is widely applied to the industries of food, beverage, drug, electronics, hardware, etc.， provides enterprises with reliable-quality and suitable-price inkjet printing solutions.
wholesale highspeed from China for label
Model Number:
C1
MOQ:
1 Set
Payment:
L/C,T/T
Place of Origin:
Guangdong,China
Delivery Time:
Delivery within one month after receipt of deposit
Shipment:
Transportation by sea
Product Details
Next, Arojet will present you with the specific details of industrial inkjet printer.industrial inkjet printer, manufactured based on high-quality materials and advanced technology, has reasonable structure, excellent performance, stable quality, and long-lasting durability. It is a reliable product which is widely recognized in the market.
1. Quality debugging will be carried out when Arojet industrial inkjet marking is produced. The debugging aspects include parts' connection, configuration, structural stability, and other mechanical performance.
2. has found increasingly wider application due to its advantages of long service life, low coat and industrial inkjet marking .
3. Strict quality inspections are carried out before delivery to increase its qualification ratio.
4. Works can get rid of jobs that are dirty dull. They will take more interest in their work and their efficiency will increase.
5. With high operational accuracy, the product is not likely to occur errors, which eventually beneficial to reduce production costs.
Product Oerview
C1 sheet-fed digital variable data inkjet printing machine is suitable for different materials with different shapes. For example, it can print variable data barcode, two-dimension code, serial No., date code, etc. on bottle cap, glass cup, ceramics, metal and so on. The printing speed is 0-45m/min with physical resolution up to 360dpi.
The resolution can reach 200dpi at the speed of 50m/min. The inkjet printing grade can reach A level and the scanning qualified rate up to 99.9%. The minimum character to be printed is 1mm. The minimum size of two-dimension code printed is 5*5mm.
Product Features
◈ Single sheet or roll to roll feeding platform
◈ Industrial piezoelectric printhead with high precision.
◈ UV-LED curing with high quality.
◈ Eco-friendly water cooling system.
◈ Wide range of printed media material.
◈ Large applications of inkjet coding and marking.
Product Specifications
Model: | C1 | Printing software: | MagicData variable data-editing software |
Print head type: | Industrial piezoelectric print head (KONICA) | SDK: | Provide interface to support second development |
Print head life: | 100 billion actuations per print head | Ink control: | Negative pressure for ink control, positive pressure for nozzle cleaning |
Print head material: | Stainless steel, Nickel alloys & Epoxy adhesive | Ink type: | High-quality Eco-friendly UV ink |
Print head width: | 36mm (single print head) | Ink color | Single color |
Nozzle quantity: | 512 pcs (single print head) | Curing type: | UV-LED curing |
Nozzle rows: | 2 rows | Printing speed: | 0-45m/min. (Affected by material, resolution, environment, platform etc. factors) |
Printing modules: | 8 groups | Lengthways printing precision: | 360dpi |
Max. width of printing: | 288mm | Crosswise printing precision: | 200dpi-1200dpi adjustable |
Distance from print head to material: | 0.5mm-2mm | Weight: | 270KG |
Material feeding way: | Single piece, roll to roll | Size: | 1.39m*0.83m*1.50m (print head case+curing case) |
Power supply: | AC 100V-240V, 50Hz-60Hz | Working temperature: | 5°C-40°C |
Interface type: | USB 2.0 | Environment humidity: | 20%-65% RH |
Product Videos
Product Applications
● Can be installed online in the platforms as below:
◇ Sheet feeding platform
◇ Polishing & laminating equipment
◇ Bottle cap machine
◇ Paging machine
◇ Labeling machine
● Can be applied to a wide range of industries as below:
◇ Packaging industry for inkjet printing of One-dimensional code, two-dimensional code, identification code, etc.
◇ Paper, plastic, card, board
◇ Tinplate, glass, ceramics
◇ Food, beverage and wine
◇ Medicine, drug and health care product
◇ Hardware, electronics, daily chemicals, building materials
Print Head
C1 model adopts KONICA all-steel piezoelectric printhead, with compact design and high precision. It can offer a range of solutions to various customer applications.
※ Shear mode, piezoelectric DOD printhead
※ 512 nozzles, 360dpi high resolution
※ Compatible with UV ink with good printing effect
※ Easy to operation with negative pressure ink control
Printing Software
C1 model uses AROJET self-designed MagicData software, which is specially developed for monochrome and multi-color variable data printing (VDP), supporting many types of object to be printed, such as texts, dates, times, graphics, logos, serial numbers, QR codes, barcodes, MICR fonts and photo images.
MagicData software has a friendly interface, easy to understand and easy to operate. Its workflow of editing, modifying, typesetting, integrating, splitting as well as input and output is brief and streamlined. It provides versatile choices to your inkjet printing solution.
Printing Ink
UV ink is a kind of economical, efficient and green eco-friendly ink, which has covered all printing industries. C1 model adopts professional UU-8008-1 type UV ink for inkjet printing. It features fast drying, vivid image and good printing quality as well as below unique characteristics.
※ Inkjet printability
※ Anti-scratch, friction resistance and anti-corrosive
※ Hazardous substance content conforms to RoHS standard.
Company Features
1. Arojet has been devoted itself into providing qualified .
2. Guangdong AROJET Ink Jet Technology Co., Ltd. has several advanced batch code printer production facilities.
3. Arojet dreams can lead the industrial inkjet marking industry development. Please contact us! Arojet Inkjet Marking Machine serves customers, understands your needs and try our best to satisfy your requirements. Please contact us! Arojet strives to win the market by its highest quality inkjet coder and most praised customer service. Please contact us! Arojet has made up the mind to acquire the industrial inkjet printing marketplace. Please contact us!
CNC controller+ monitor+ operation panel+stand alone THC
We can offer best solution for your CNC plasma&flame cutting machine building project.
The digital controller HYD2500 is a new production, which is integrated many merits of the same productions at home and aboard. The controller can control the motion of two axis, which is apt to the application of flame or plasma cutting. This controller is very light and handy and it is very easy to operate. The controller provides menu or illustration for all the operations for the convenience of users. All key switches are human oriented designed, and they are very convenient and comfortable.
The controller chooses high speed DSP and ARM as its core to assure the cutting process to be more stable. The motion control algorithm is optimized so that the machine can move more stale and reliable, and it can save the life of the motor and the mechanical parts.
TECHNICAL STANDARD
1) Control Axis:2
2) Control accuracy :+/-0.001mm
3) Coordinate range:+/- 99999.999mm
4) Max pulses : 200kHz Max speed:15000 mm/m
5) Max lines of code:150000lines
6) Max size of single code file:4M
7) Time resolution :10ms
8) Working Voltage: DC 24V in put
9) Working Temperature:-10°C-60°C. Relative Humidity, 0-95%.
SYSTEM INTERFACE
1) 15 pins interface of 2 axis of motor drive.
2) 25 pins interface of 16 channels optical couple output ports,max back flow current 300mA.
3) 25 pins interface of 16 channels optical couple input ports,max output current 300mA.
4) USB interface on the front panel.
5) Extend IO input/output ports, PWM input ports, analog input ports.
HARDWARE CONFIGURATION
1) Monitor:15 inch, 1024*768, high definition 16 million colors and high brightness LCD or 10.4 inch 800*600, 26 million color LCD.
2) Memory: 64M SDRAM
3) Memory available for user: 256M or 1G electronic hard disk
4) System master frequency: 400MHz
5) USB: USB 1.1 front interface
6) Keyboard: electronic PCB foil keyboard( one machine) or standard industrial keyboard(split type machine)
7) Chassis: full-steel structure completely shielded which defends electromagnetic radiation, interference and static electricity.
Product Overviews
MEILI POWER PRESS MACHINE
(1)Features:
1.Computer optimized design, 3-beam, 4-column structure, simple but with high performance price ratio.
2.Plug in valve integral unit equipped for hydraulic control system, realiable, durable and less hydraulic shock, with shorter connection pipeline and fewer releases points.
3.Independent electrical control, reliable, audio-visual and convenient for maintenance.
4.Centralized button control system, with adjustment, hand and semi-auto operation modes at operator's choice.
5.Fixed stroke forming process or fixed pressure forming process selected through
control panel, with pressure hold and time delay functions.
6.The operating force, no-load traveling and, low-speed movement and travel range
can be adjusted subject to technological requirements.
(2)Application:
A.This series of four-column hydraulic press machine presses with a wide range of versatility, suitable for various kinds of metal materials tensile, bending, flanging, cold extrusion, blanking process.
B.It applies to the correction, pressfit, powder products, abrasive products, grinding wheel, bakelite, resin, thermosetting products forming and press-formed in the insulating material of the plastic products.
(3)Optional configuration:
a.Cutting Dampening system
b.Oil heating/cooling unit
c.Displacement sensor
d.Industrial touching screen monitor
e.PLC programmable controller
f.Floating guide-way and rolling bracket for die exchange
g.Working area lighting
h.Quick die clamping device
i.Light curtain safety device
