AROJET industrial inkjet printer suppliers - a high-tech enterprise for industrial inkjet printing solutions

custom uv inkjet label printer variable from China for paper 1
custom uv inkjet label printer variable from China for paper 2
custom uv inkjet label printer variable from China for paper 3
custom uv inkjet label printer variable from China for paper 4
custom uv inkjet label printer variable from China for paper 5
custom uv inkjet label printer variable from China for paper 6
custom uv inkjet label printer variable from China for paper 7
custom uv inkjet label printer variable from China for paper 8
custom uv inkjet label printer variable from China for paper 9
custom uv inkjet label printer variable from China for paper 10
custom uv inkjet label printer variable from China for paper 1
custom uv inkjet label printer variable from China for paper 2
custom uv inkjet label printer variable from China for paper 3
custom uv inkjet label printer variable from China for paper 4
custom uv inkjet label printer variable from China for paper 5
custom uv inkjet label printer variable from China for paper 6
custom uv inkjet label printer variable from China for paper 7
custom uv inkjet label printer variable from China for paper 8
custom uv inkjet label printer variable from China for paper 9
custom uv inkjet label printer variable from China for paper 10

custom uv inkjet label printer variable from China for paper

Model Number:
X1
MOQ:
1 Set
Payment:
L/C,T/T
Place of Origin:
Guangdong,China
Delivery Time:
Delivery within one month after receipt of deposit
Shipment:
Transportation by sea
Inquiry
Company Advantages
1. The materials for Arojet are industrial standard and are procured from trusted vendors of the market. The product is not easy to rust and is highly resistant to harsh conditions
2. I bought it and gave it to my friend as a gift. She said that was the first time she received such a special gift and she treasured it so much. The product is compatible with materials with various shapes
3. The product is free of toxic chemical substances. At the stage of materials or ingredient extraction and testing, the raw materials or components are totally tested to be harmless. The product is provided with OED and OEM service
4. This product comes with moisture and mold resistance, making it ideal for these high humidity areas by reducing the effect of water on the surfaces. The product can run super smoothly and noiselessly

Product Oerview

Model X1 is very popular with our customers because of its high cost-effective performance. At the same time of its affordable price, the printing speed and precision have reached a high level too. It also can meet the customer requirements. It is the first recommendation of our sales team submitted to the customers.

X1 is suitable for both roll to roll and sheet-fed inkjet printing, with its printing speed up to 150m/min. and the printing definition up to 600dpi*1200dpi. The printing effect is outstanding and the UV-LED curing quality is excellent.

X1 model is widely applied to many industries for the variable data printing on label, flexible packaging, film, plastic, card and sheet, such as variable one-dimension code of GS1 DataBar/RSS, compound barcode, and electronic monitoring code, variable two-dimension code of QR code, DATAMATRIX, Chinese character code and atomic code, identification code of picture, word and number, and so on.


custom uv inkjet label printer variable from China for paper 11

  • We are dedicated to tailor-made our customers, to provide you with economically feasible variable data inkjet printing solutions, and help your business to a new expansion.

custom uv inkjet label printer variable from China for paper 12


Product Features

  • ◈  High cost performance, economical and practical.

  • ◈  High printing precision and high printing quality.

  • ◈  Resolution: 600*300dpi, speed: 150m/min.

  • ◈  Resolution: 600*400dpi, speed: 100m/min.

  • ◈  Resolution: 600*600dpi, speed: 60m/min.

  • ◈  Simple installation and easy operation.

  • ◈  Negative pressure for ink control, positive pressure for nozzle cleaning.

  • ◈  Reconfiguration of hardware and software according to customer requirements.

  • ◈  Widely compatible. Can be installed in customer current production line, or can be configured by AROJET along with the printing system.


custom uv inkjet label printer variable from China for paper 13


Product Specifications

Model:

X1

Printing software:

MagicData variable data-editing software

Print head type:

Industrial piezoelectric print head
     (GEN5 A+ RICOH)

SDK:

Provide interface to support second development

Print head life:

150 billion actuations per print head
     (GEN5 A+ RICOH)

Ink control:

Negative pressure for ink control, positive pressure for nozzle cleaning

Print head material:

Stainless steel, Nickel alloys & Epoxy adhesive

Ink type:

High-quality Eco-friendly UV ink

Print head width:

54mm (single print head)

Ink color

Single color

Nozzle quantity:

1280 pcs (single print head)

Curing type:

UV-LED curing

Nozzle rows:

4 rows

Printing speed:

0-150m/min. (Affected by material, resolution, environment, platform etc. factors)

Printing modules:

4 groups

Lengthways printing precision:

600dpi

Max. width of printing:

432mm

Crosswise printing precision:

200dpi-1200dpi adjustable

Distance from print head to material:

0.5mm-2mm

Weight:

270KG

Material feeding way:

Single piece, roll to roll

Size:

1.39m*0.83m*1.50m (print head case+curing case)

Power supply:

AC 100V-240V, 50Hz-60Hz

Working temperature:

5°C-40°C

Interface type:

USB 3.0 optical fiber data transmission

Environment humidity:

20%-65% RH

Product Videos



Product Applications

● Can be installed online in the platforms as below:

Polishing and coating equipment

Slicing and slitting machine

Inspection machine

Flexo printing press

Bagging machine

Label printing press

Paging machine

Bagging machine

Paper box slotting machine

Paste box machine

custom uv inkjet label printer variable from China for paper 14
● Can be applied to a wide range of industries as below:

Label, flexible packaging

Plastic, film

Card, nameplate,board material

Barcodes, QR codes, variable graphics and characters

Food, beverage and wine

Medicine, drug and health care product

custom uv inkjet label printer variable from China for paper 15

Print Head

AROJET X1 model uses RICOH GEN 5 piezoelectric print head with variable ink droplet printing. The ink droplet is 7pl minimum and 35pl Maximum, which can reach photographic precision. The nozzle is an all-steel material and is not easy corroded and blocked. It can intelligently avoids blank printing, greatly saving ink. The nozzle has a long service life of 150 billion actuations. Human friendly design enables it to print many materials of different thickness. The print head can achieve perfect seamless stitches with tolerance less than 0.5mm.


Model X1 has a stable and reliable quality, brings you high-efficient and high quality inkjet printing service.


custom uv inkjet label printer variable from China for paper 16


Printing Software

MagicData is professional software designed and developed for industrial inkjet printing applications. It offers fast RIP speed, reliable & efficient job printing production, and streamlined workflow. Users can easily obtain smooth gradient, vivid images and sharp small size text with its advanced RIP technology.

Model X1 in which MagicData software is adopted brings the customers with much wider and more flexible range of printing choice, to achieve high quality and high efficient printing production.

  • ※  Object template

  • ※  Ink estimation

  • ※  Intuitive preview

custom uv inkjet label printer variable from China for paper 17


Printing Ink

AROJET inkjet printing machines use greens environmental-protective UV ink, which do not contain VOC (volatile organic compounds)substances, The UV ink which printed on the materials can achieve fast drying through AROJET patent-designed UV-LED curing water cooling system, which makes the printing high-adhesive, anti-scratching, friction-resistant and alcohol-resistant. It is widely used in variable inkjet coding on different materials of different thickness.

Model X1 adopts single-color UV ink for printing. Thanks to the stable inkjet quality and outstanding inkjet printing effect, it has been highly praised by many of our customers. We regularly update ink SGS reports and review the MSDS reports of the ink material.

  • ※  Greens and environmental-protective

  • ※  Quick drying and high adhesion

custom uv inkjet label printer variable from China for paper 18
custom uv inkjet label printer variable from China for paper 19
custom uv inkjet label printer variable from China for paper 20
custom uv inkjet label printer variable from China for paper 21

Company Features
1. Guangdong AROJET Ink Jet Technology Co., Ltd. is well-known in China market. The key competence of our company is an outstanding capability in manufacturing .
2. Our company has attracted a large pool of senior technical elites. They have years of abundant practical experience in manufacture expertise, which makes them respond to any problems quickly and flexibly.
3. We constantly seek to improve energy and resource consumption during production by consistently reviewing our processes and implementing individual site initiatives such as eco-efficient lighting, insulation, and heating systems.
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
no data
The company' s products are widely used in many industries, with excellent quality and technology to win a number of honorary titles, access to a number of patents.
