Debit Credit Gift Smart Cards UV Digital Press Printing Machine

Debit Credit Gift Smart Cards UV Digital Press Printing Machine

Get Latest Price
Get the latest price
Quantity Needed:

Basic Info.

Model NO.
UV Ink
Print Head Type
on-Demand Piezoelectric Print Head(Konica)
Print Head Life
100 Billion Actuations Per Print Head
Print Head Width
36 mm
Ink Color
Single Color
Curing Type
UV-LED Curing
Printing Speed
0-45 M/Min
218 Kg
Printing Software
Magicdata Variable Data-Editing Software
Ink Control
Negative Pressure for Ink Control
Ink Type
High-Quality Eco-Friendly UV Ink
Lengthways Printing Precision
600 Dpi
Crosswise Printing Precision
200 Dpi-1200 Dpi Adjustable
Material Feeding Way
Single Sheet/Roll to Roll
Power Supply
AC 100V-240V, 50Hz-60Hz, 2.7kw
Transport Package
Wooden Case
139*83*150 cm
HS Code

1. production overview

C1 sheet-fed digital variable data inkjet printing machine is suitable for different materials with different shapes. For example, it can print variable data barcode, two-dimension code, serial No., date code, etc. on bottle cap, glass cup, ceramics, metal and so on. The printing speed is 0-45m/min with physical resolution up to 360dpi.

The resolution can reach 200dpi at the speed of 50m/min. The inkjet printing grade can reach A level and the scanning qualified rate up to 99.9%. The minimum character to be printed is 1mm. The minimum size of two-dimension code printed is 5*5mm.

Sheet-fed featured C1 model can be used for roll to roll printing too when the printing speed is not required too high. It is widely applied to the industries of food, beverage, drug, electronics, hardware, etc., provides enterprises with reliable-quality and suitable-price inkjet printing solutions.

Debit Credit Gift Smart Cards UV Digital Press Printing Machine

2.Product Features

  Single sheet or roll to roll feeding platform

  Industrial piezoelectric printhead with high precision.

  UV-LED curing with high quality.

  Eco-friendly water cooling system.

 Wide range of printed media material.

 Large applications of inkjet coding and marking.

Debit Credit Gift Smart Cards UV Digital Press Printing Machine

3.Product Specifications

Model:C1Printing software:MagicData variable data-editing software
Print head type:Industrial piezoelectric print head (KONICA)SDK:Provide interface to support second development
Print head life:100 billion actuations per print headInk control:Negative pressure for ink control, positive pressure for nozzle cleaning
Print head material:Stainless steel, Nickel alloys & Epoxy adhesiveInk type:High-quality Eco-friendly UV ink
Print head width:36mm (single print head)Ink colorSingle color
Nozzle quantity:512 pcs (single print head)Curing type: UV-LED curing
Nozzle rows:2 rowsPrinting speed:0-45m/min. (Affected by material, resolution, environment, platform etc. factors)
Printing modules:8 groupsLengthways printing precision:360dpi
Max. width of printing:288mmCrosswise printing precision:200dpi-1200dpi adjustable
Distance from print head to material:0.5mm-2mmWeight:270KG
Material feeding way:Single piece, roll to rollSize:1.39m*0.83m*1.50m (print head case+curing case)
Power supply:AC 100V-240V, 50Hz-60HzWorking temperature:5°C-40°C
Interface type:USB 2.0Environment humidity:20%-65% RH

4.Print Head

C1 model adopts KONICA all-steel piezoelectric printhead, with compact design and high precision. It can offer a range of solutions to various customer applications.

       Shear mode, piezoelectric DOD printhead

       512 nozzles, 360dpi high resolution

       Compatible with UV ink with good printing effect

       Easy to operation with negative pressure ink control

5.Printing Software

C1 model uses AROJET self-designed MagicData software, which is specially developed for monochrome and multi-color variable data printing (VDP), supporting many types of object to be printed, such as texts, dates, times, graphics, logos, serial numbers, QR codes, barcodes, MICR fonts and photo images.

MagicData software has a friendly interface, easy to understand and easy to operate. Its workflow of editing, modifying, typesetting, integrating, splitting as well as input and output is brief and streamlined. It provides versatile choices to your inkjet printing solution.

Debit Credit Gift Smart Cards UV Digital Press Printing Machine

6.Printing Ink

UV ink is a kind of economical, efficient and green eco-friendly ink, which has covered all printing industries. C1 model adopts professional UU-8008-1 type UV ink for inkjet printing. It features fast drying, vivid image and good printing quality as well as below unique characteristics.

  •  Inkjet printability

  •  Anti-scratch, friction resistance and anti-corrosive

  •  Hazardous substance content conforms to RoHS standard.

Debit Credit Gift Smart Cards UV Digital Press Printing Machine

7.Reference Video

By years of accumulation, Arojet has established perfect quality assurance and managing system to assure industrial inkjet printer's quality. The product is characterized by a high resolution. Strictly controlling manufacture key process effectively ensures the quality of industrial inkjet printer. The product is characterized by a high resolution.
