Arojet ultrahigh industrial inkjet marking factor for label
1. Each step of Arojetinkjet printing machine production is carefully and rigorously monitored.
2. Commercially manufactured inkjet printing machine are industrial inkjet marking .
3. Many customers are satisfied with the quality of inkjet printing machine .
Product Oerview
Product Overview: EM-313W color UV digital printing system launched by AROJET is manufactured by utilizing UV inkjet printing technology and high-quality precision components. It supports four-color/five-color, white ink, varnish or spot color printing. It can print 2000mm long documents at a print speed of up to 50m/min. It supports printing variable data such as bar codes, serial numbers, dates, times, text, logos or images.
It can be equipped with a variety of post-press processing modules, and can also be combined with diverse processing processes, such as cold ironing, glazing, laminating and die-cutting, so to meet your growing personalized needs.
Product Features
◈ LableBijin (editing software)
◈ LabelMeister RIP (color separation + Inkjet printing )software
The simple printing process that breaks through technical bottlenecks Extremely low printing cost, excellent printing effect, minimal system investment, digital operation, and limited space occupation make the system have greater market prospects. It is a new generation of printing machine with more outstanding performance. It works in a simple process: manual design - document output - digital printing - cross-cutting. Compared with the traditional printing mode, it eliminates the two processes of drying film and plate making, which greatly reduces the cost and improves the production efficiency.
Variable data printing & Secondary printing &Long-format printing
Color UV digital system can not only edit variable data (such as QR code, bar codes, text, etc.) from CSV file but also widely support variable images in BMP, TIFF, JPG and other formats. The printed materials can be used directly without coating treatment (Treatment before printing is recommended).
The color UV digital printing system is equipped with intelligent secondary printing. It can print special color and variable one or two-dimensional code after one printing, and can also print on the blank label after die-cutting. When the image interval is set to 0mm, a long format with the length of 220mm*2000mm (2mm) can be printed seamlessly.
Product Parameter
Paper delivery: roll to roll | Printing size: general 220*2000mm/ variable data 220*400mm |
Printing method: inkjet | Material parameters: width: 100-250mm/ large diameter: 400mm/ weight: 25kg |
Print head: piezoelectric print head | Equipment size: 3540*1000*1410mm(L/W/H) |
Resolution: 600*600dpi 600*1200dpi | Printing speed: 25m/min(600,1200dpi)/50m/min(600,600dpi) |
Effective printing width: 220mm | Curing mode: UV curing (LED UV lamp/air-cooled UV lamp) |
Print thickness: 0.1-0.6mm | Ink quantity: 2L*5 (1 bottle per color)/detergent 2L*2 |
Paper tube diameter: 76m | Applicable software: LabeIMeister RIP/ editing software |
Equipment weight: 750kg | Environmental requirements: temperature 20-30 degrees/humidity 50-70% |
Ink: Eco-friendly UV ink (C.M.Y.K.W) | Power: 3 AC200V 8KAV(50/60hz) |
Applicable materials: paper, film;/ self-adhesive/non-self-adhesive (printing test is recommended) | |
Product Videos
Product Applications
◇ The portable ink bottle is safe and convenient to change. The printing process eliminates the process of making a version and reduces paper waste. The piezoelectric nozzle can be automatically cleaned, and other parts only need regular maintenance.
◇ The environmentally-friendly white ink can be directly printed on the substrate without a white background. It can also bring a partial glazing effect on a white substrate. The high-end nozzle ensures controlled flow-level printing for high-quality image and picture.
EM-313W color UV digital printing system is a new generation of printing machines.
Company Features
1. In terms of industrial inkjet marking , Guangdong AROJET Ink Jet Technology Co., Ltd. ranks first among strong manufacturers.
2. inkjet printing machine is exquisitely made by the advanced machines.
3. high speed industrial inkjet printer is Guangdong AROJET Ink Jet Technology Co., Ltd. original service philosophy, which fully shows its own superiority. Inquiry! To establish the service idea of industrial marking equipment is the base of Guangdong AROJET Ink Jet Technology Co., Ltd.'s work. Inquiry! Guangdong AROJET Ink Jet Technology Co., Ltd. has established the service notion of inkjet date printer . Inquiry! inkjet coding equipment has become the perpetual pursuit of Guangdong AROJET Ink Jet Technology Co., Ltd. to improve himself. Inquiry!
